Blue Water-Based pH Neutral PEDOT:PSS Dispersion
Used for applications in HIL and OFET backplanes
| |
P JET (OLED), CAS number 155090-83-8, is a blue water-based pH neutral dispersion formulated for inkjet printing. As a hole injection layer and antistatic material, P JET (OLED) finds application in OLED and QLED devices to improve the performance and processing of displays, as well as OFET backplanes.
Neutral pH
Allowing transmission of light to pass into active layer
Versatile Use
Used for applications in HIL and OFET backplanes
High Quality
Quality formulation
Tailored Low Conductivity
Low conductivity
Technical Data
| Product Name | Clevios™ P JET (OLED) |
|---|---|
| Solvent | Water |
| Composition | PEDOT/PSS (1:6 w/w) |
| CAS Number | 155090-83-8 |
| Solid Content | 1.6 – 2.1 wt.% |
| Work Function | 5.2 eV approx |
| Resistivity | 1000 – 15000 Ω.cm |
| Sheet Resistance | 10E6 Ω/sq |
| Conductivity | Low conductivity |
| Particle Size Distribution | N/A |
| Viscosity | 4 – 20 mPa.s |
| pH Value | 4.0 – 7.0 |
| Packaging | 25 ml of solution sealed in a light resistant bottle with temperature indicator |
| Storage | 3 – 5 °C |
Spin Speed Data
MSDS Document
Resources and Support
For the deposition of thin films of PEDOT:PSS on a freshly prepared surface, we recommend using a vacuum-free spin coater and following this five-step process:
PEDOT synthesis involves the oxidative chemical or electrochemical polymerization of EDOT monomer. The choice of counterions and polymerization method significantly affects the conductivity, work function, and stability of the resulting PEDOT polymer.
